Window installation requires the use of many rivets. So do you know how window rivets work?Do you know how to choose the right rivets for window?
Table of Contents
Why Use Rivets for Window?
Rivets are a very common fastener used in the installation and maintenance of windows.Window rivets are commonly used to attach and secure window frames, glass brackets and other components. So why use rivets on windows? Here are the main reasons for using rivets:
1. Rivets can Provide Strong and Reliable Connections
The windows are usually opened outwards during use. So windows are usually used under strong winds or external pressure. In the case of plants, window rivets need to withstand the high strength of fixing required by window frames and brackets, and maintain the stability of the connection.
In addition to this, window rivets have good vibration resistance. Even if the window is subjected to prolonged vibration or impact, the rivets will still maintain a strong connection.
2. Suitable for One-sided Installation
Many components of a window (such as glass brackets or exterior trim) may only allow for one-sided operation. And operating space is tight. Rivets are ideal for this purpose because they can be installed from one side.
The rivet installation process is known to be very quick and easy. When using blind rivets to install a window, the operator only needs to complete the installation from one side, without touching the back of the window. This feature greatly simplifies the construction and improves the efficiency of the installation. The operator also does not need to be trained, only need to have a rivet gun to complete the entire installation process.
Types of Window Rivets
There are several different types of window rivets depending on the nature of the window and the scenario in which it is used. The following are common window rivets.
Blind Rivets for Window
The benefits of using blind rivets on windows are numerous. For example, single side installation, multiple materials and the ability to rivet many different materials. Common types of window blind rivets are these:
- Sealed Rivets: Strong waterproof performance. Allows for outdoor window frame installation and window fixing in high humidity environments.
- Grooved Rivets: The exterior is grooved to create a stronger bite in plastic or soft materials. Often used to secure PVC window frames or other soft materials. Grooved rivets are also sometimes used when extra stability is required for window frame fitting.
- Tri Fold Rivets: Tri fold rivets increase contact area and clamping force and are ideal for joining thin plates or soft materials. Examples include the installation of thin metal window frames and the fixing of wooden window frames to glass components.
- Multi Grip Rivets: A wide range of different thicknesses can be riveted. Multi grip blind rivets are often used to join aluminum window frames to other materials and to assemble window assemblies of different thicknesses.
Solid Rivets for Window
Solid rivets are also commonly used for window rivets. they provide extreme strength for window connections. Ideal for areas subject to high loads or vibration. However, solid rivets must be accessible from both sides to be installed.
Solid rivets are generally used for heavy frames or highly stressed windows. Solid rivets are also chosen for industrial windows or for fixing the exterior of buildings.
Self Piercing Rivets for Window
The big difference with Self piercing rivets is that there is no need to pre-drill. It penetrates right through the window frame material and holds it in place. SPR Rivets provide a high-strength connection while reducing installation steps and increasing efficiency.
When your project is one that requires a multi-layer metal window frame installation, self piercing rivets are the best solution.
Do You Have Any Questions?
Let Us Solve Your Problem
What is the Difference Between Blind Rivets and Solid Rivets for Windows?
| Comparison Factor | Blind Rivets | Solid Rivets |
| Installation Method | Single-sided installation: Operates from one side, ideal for inaccessible areas. | Double-sided installation: Requires access to both sides, typically secured with hammering tools. |
| Installation Difficulty | Easy to install, requires only a rivet gun. | Complex installation, needs specialized tools (e.g., hammer or press) and skilled operation. |
| Suitable Materials | Works with aluminum, plastic, steel, composite materials, especially thin sheets. | Suitable for thick plates or metal materials, ideal for high-strength connections. |
| Application Scenarios | – Window frame to glass bracket | – Heavy-duty window structures |
| – External trims | – High-strength metal frames | |
| – PVC or aluminum frames | – Industrial windows | |
| Strength and Load Capacity | Moderate strength, suitable for light to medium loads, mainly for decorative or lightweight connections. | High strength, suitable for heavy loads and high-vibration components. |
| Water Resistance | Sealed blind rivets can provide water resistance. | Typically not waterproof, requires additional sealing. |
| Space Constraints | Ideal for constrained spaces, such as narrow window frames where only one side is accessible. | Requires space to access both sides, less versatile in tight areas. |
| Aesthetic Appearance | Clean surface post-installation, minimal protrusion, suitable for visually appealing designs. | Rivet heads may protrude, typically used in concealed internal connections. |
| Durability | Moderate durability, suitable for low to medium loads and mild environments. | High durability, suitable for long-term use in harsh environments. |
| Tool Requirements | Requires manual, electric, or pneumatic rivet guns; portable and easy to operate. | Requires tools like hammers or presses, bulkier equipment. |
| Material Cost | Relatively low cost, ideal for mass production and lightweight window frames. | Higher material and processing costs, suitable for high-strength and industrial applications. |
Blind Rivet:
- Suitable for lightweight window frames (e.g. aluminum, PVC window frames) and scenarios that require one-sided installation.
- Commonly used in the fixing of external window frames, trims or glass brackets.
- Preferred for high requirements on installation convenience and appearance.
Solid Rivets:
- Ideal for high load or heavy duty window construction such as industrial windows or metal window frames.
- Used for connections requiring high strength and long term durability.
- Ideal for scenarios where high reliability is sought and there are no restrictions on installation space.
Why Choose Rivets over Screws or Welding for Window Installations?
In window installations, rivets are more suitable than screws for permanent connections, with essentially no risk of loosening. Welding can cause damage to the window material. Therefore, rivets are the most common and efficient choice for window installation. Below is a comparison of rivets and screws, and welding.
When it comes to window installation, rivets have the following advantages over screws:
- Single-sided installation for tight spaces.
- Excellent vibration resistance for high vibration environments.
- Flat surface after riveting.
- Suitable for permanent joining of a wide range of materials.
- Provides a long-term stable connection without subsequent maintenance.
Rivets also have many unique advantages over welding:
- There is no need to operate at high temperatures.
- No thermal effects. Does not cause deformation of the material.
- Can be operated indoors or on site.
Do You Have Any Questions?
Let Us Solve Your Problem
How to Remove Rivets in a Window Frame?
Rivets are known to be a permanent connection. Therefore, removing rivets only destroys the structure of the rivet. You need to prepare the following tools:
- Electric drill or hand drill
- Drill head
- Center Punch
- Hammer
- Pry bar or sharp-nosed pliers
- Protecting Equipment
Removal Steps：
- Determine rivet location and type
- Marking the rivet center
- Drill off the rivet head
- Remove the rivet bar
- Checking the holes
